material

Material
Material frontside: Aluminium AlMg1
Si: 0,30
Fe: 0,70
Cu: 0,20
Mn: 0,20
Mg: 0,50/1,10
Cr: 0,10
Zn: 0,25
Ti: -
Tensile Strength: 140 - 180 N/mm²
0.2 limit of elasticity: 120 N/mm²

Surface
Anodisation: 20 micron
Type: E6 EV1
Chemically treated: Yes
Natural colour - matt: Yes
Useable on 1 side (other only 8 anodisation): Yes
4 anodisation points: Yes

Fire resistance
Fire resistance: non flammable (DIN 4102)

Usage
Usage: interior/exterior

For all accessoiries, please download our technical catalogue
in the download section.

Measurements table

What	Value	Toleration
Number:	600010
Lenght:	2500 mm	± 10 mm
Width:	1000 mm	± 2 mm
Sheet thickness:	1 mm	DIN
Squareness:	-	± 0,3% on L
Surface area:	± 2,5 m²	± 0,05 m²
Weight:	6,3 kg/pc (2,5 kg/m²)
Ridge height:	2 mm	± 0,5 mm
Ridge length:	9,6 mm	± 0,2 mm
No. of ridges:	104
Fold direction:	2500 mm direction

treatments

Cutting: Yes
Trimming: Yes
Edge Rolling: Yes
Waterjet: Yes
Milling: Yes
Squaring: Yes
Laser: Yes
